The AMD Ryzen 7 3800X is a high-performance desktop processor built on AMD’s advanced Zen 2 architecture and a cutting-edge 7nm manufacturing process. Designed for gamers, creators, and power users, it delivers an excellent balance of speed, efficiency, and multitasking power.
With 8 cores and 16 threads, the Ryzen 7 3800X is capable of handling demanding workloads such as video editing, 3D rendering, streaming, and high-end gaming with ease. It features a base clock of 3.9 GHz and can boost up to 4.5 GHz, ensuring responsive performance across both single-threaded and multi-threaded applications.
The processor is equipped with a large 32MB L3 cache, dual-channel DDR4 memory support (up to 3200 MHz officially), and PCIe 4.0 lanes, making it future-ready for fast storage solutions and the latest GPUs. With a TDP of 105W, it balances power consumption and performance effectively, while the included Wraith Prism cooler with RGB lighting offers reliable cooling and a premium look out of the box.
Whether you are building a gaming rig, a workstation, or a versatile all-round PC, the Ryzen 7 3800X stands out as a powerful choice that delivers strong performance and exceptional value.
Description of AMD 3800x Ryzen 7
General Specifications
Platform – Boxed Processor
Product Family- AMD Ryzenâ„¢ Processors
Product Line – AMD Ryzenâ„¢ 7 Desktop Processors
Former Codename- “Matisse”
# of CPU Cores- 8
# of Threads – 16
Max. Boost Clock – Up to 4.5GHz
Base Clock- 3.GHz
L1 Cache – 512KB
L2 Cache – 4MB
L3 Cache- 32MB
Default TDP – 105W
Processor Technology for CPU Cores- TSMC 7nm FinFET
Unlocked for Overclocking – Yes
CPU Socket – AM4
Thermal Solution (PIB) –Wraith Prism wih RGB LED
Thermal Solution (MPK) – Wraith Prism
Max. Operating Temperature (Tjmax) – 95°C
Launch Date – 7/7/2019
*OS Support – Windows 10 – 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit,
Connectivity.
PCI Express® Version – PCIe 4.0 x16
System Memory Type -DDR4
Memory Channels – 2
System Memory Specification – Up to 3200MHz
Graphics Capabilities
Integrated Graphics -No
Graphics Model – Discrete Graphics Card Required
Warranty:
Product is thoroughly tested and completely functional without any issues. We also provide a one-month warranty from our end.
Specifications of AMD 3800x Ryzen 7 :
| Number Of CPU Cores | 8 |
| Number Of CPU Threads | 16 |
| Max Boost Clock | 4.5GHz |
| Base Clock | 3.9GHz |
| Separate Graphics Card support | YES (MANDATORY) |
| PCIe Version | 4 |
| Total L2 Cache | 4MB |
| Total L3 Cache | 32MB |
| CMOS | TSMC 7nm FinFET |
| System Memory Specification | 3200MHz |
| System Memory Type | DDR4 |
| Memory Channels | 2 |
| TDP | 105W |
| Unlocked | Yes |
| In Box Cooler | Wraith Prism |
| Socket | AM4 |
| OPN PIB | 100-100000025BOX |
| Warranty | 3 years from Manufacture |
| Note | ***Features, Price and Specifications are subject to change without notice. |
